Chapter 2 Quick start
2.1 Install the SIM card and temperature sensor
Turn the power switch to “OFF” position.
Loosen the screw and open the socket’s SIM cover; you will see a
SIM card holder.
Push the metallic cover of the holder to “OPEN” direction and open
the SIM card holder.
Put the SIM card on the card holder, ensuring that the beveled
corner is toward the beveled corner of the SIM holder and the golden
contact area is facing downwards.
Cover back the metallic cover and push it to “LOCK” direction. The
SIM card will be fixed in the holder.
Screw the SIM cover back.
Insert the temperature sensor into the I/O port until it is seized.
2.2 GSM Power on/ off
Power on:
1. Turn the power switch to “On” position (See 7 on Figure1).
2. Plug the GSM Power Socket in an AC power socket (See 6 on
Figure1).
The blue light will be flashing slowly for about 20 seconds, then blue
light be on constantly and a long “Beep” tone can be heard (if “Beep”
warning tone is enabled).
The default state of the socket outlet is no power supply output.
3. Insert the plug of electronic appliance in the GSM Power Socket
electrical outlet (See 4 on Figure1).
