Table 2-5 Default Functions of the ports
Port
Name
Function
J2-1
TEMP_BAT
Detection of battery temperature
J2-2
TEMP_COM
terminal for battery temperature
J3-1
ENV_TEMP
Detection of environmental temperature
J3-2
TEMP_COM
terminal for environmental temperature
J4-1
REMOTE_EPO_NC
EPO N.C., trigger EPO when disconnected from J4-2
J4-2
+24V_DRY
+24V
J4-3
+24V_DRY
+24V
J4-4
REMOTE_EPO_NO
EPO N.O., Trigger EPO when short-circuited with J4-3
J5-1
+24V_DRY
+24V
J5-2
GEN_CONNECTED
Input dry contact, the function is settable,
Default: interface for the generator
J5-3
GND_DRY
Ground for +24V
J6-1
BCB Drive
Output dry contact, the function is settable.
Default: Battery trip signal
J6-2
BCB_Status
Input dry contact, the function is settable.
Default: BCB Status (Alarm no battery if BCB Status is invalid).
J7-1
GND_DRY
Ground for +24V
J7-2
BCB_Online
Input dry contact, the function is settable.
Default: BCB Online (when short-circuited with J7-1,
it indicates BCB online, and BCB Status is available).
J8-1
BAT_LOW_ALARM_NC
Output dry contact (Normally closed), the function is
settable.
Default: Low battery alarm
J8-2
BAT_LOW_ALARM_NO
Output dry contact (Normally open), the function is settable.
Default: Low battery alarm
J8-3
BAT_LOW_ALARM_GND
Common terminal for J8-1 and J8-2
J9-1
GENERAL_ALARM_NC
Output dry contact, (Normally closed) the function is
settable.
Default: Fault alarm
J9-2
GENERAL_ALARM_NO
Output dry contact, (Normally open) the function is settable.
Default: Fault alarm
J9-3
GENERAL_ALARM_GND
Common terminal for J9-1 and J9-2
J10-1
UTILITY_FAIL_NC
Output dry contact, (Normally closed) the function is
settable.
Default: Utility abnormal alarm
J10-2
UTILITY_FAIL_NO
Output dry contact, (Normally open) the function is settable.
Default: Utility abnormal alarm
J10-3
UTILITY_FAIL_GND
Common terminal for J10-1 and J10-2
