Note
The input dry contact ports J5-2, J6-2, and J7 can be programmed through our MTR software, the
programmable events are shown in Table 2-6.
Table 2-6 Input Programmable Events
NO.
Event
Description
1
Generator Input
The input power is supplied by the generator
2
Main CB Close
Main input breaker is closed
3
Mute
Mute
4
BCB Status
BCB status, closed or open
5
Transfer Inverter
UPS would transfer to the inverter mode
6
BCB Online
Enable the BCB status checking
7
Transfer Bypass
UPS would transfer to the bypass mode
8
Fault Clear
Recheck the fault or alarm information
9
Battery Over Charge
Batteries are over charged
10
Battery Over Discharge
Batteries are over discharging
11
Stop Boost Charge
Stop boost charging
Note: The output dry contact ports J6-1, J8, J9 and J10 can be programmed through our MTR software,
the programmable events are shown in Table 2-7.
Table 2-7 Output Programmable Events
NO.
Event
Description
1
BCB Trip
BCB tripping
2
Byp Backfeed Trip
Bypass backfeed protective breaker tripping
3
Overload
Output is overload
4
General Alarm
General alarms
5
Output Lost
No output voltage
6
Battery Mode
UPS works in battery mode
7
Utility Fail
The power-grid fails
8
On Inverter
UPS works in inverter mode
9
Battery Charge
Batteries are being charged
10
Normal Mode
UPS works in normal mode
11
Batt Volt Low
Batteries voltage is low
12
On Bypass
UPS works in bypass mode
13
Batt Discharge
Batteries are discharging
14
Rectifier Ready
The rectifier is starting
15
Battery Boost Charge
Batteries are boosting charged
Note: There below take the default definitions for example to introduce the methods of application.
