Guspro BB-8416884 - Dimensions - inches; Trim Types

Dimensions - inches
ASCO Valve – Americas
© 89 MCMXCIX All rights reserved. Printed in the USA V7193
ASCOLECTRIC limited
Brantford, Ontario N3T 5M8
Tel: (519) 758-2700
Fax: (519) 758 5540
ASCOMATICA, S. A. de C.V.
Mexico City, D. F. CP11700
Tel:(52) 5-596-77-41
Fax:(52) 5-596-77-19
ASCOVAL, Ind E Com Ltda.
06465-030 Barueri, São Paulo, Brazil
Tel: (55) 11-421-5333
Fax: (55) 11-421-5185
Automatic Switch Co.
Hanover Rd. , Florham Park, NJ 07932
Tel: (973) 966-2000 Fax: (973) 966-2628
website: www.ascovalve.com
ASCO
/ General Controls
Valencia, CA 91355
Tel: (805) 294-1770
Fax: (805) 294-1766
Quick Opening Trim
(Standard)
Quick Opening with
Valve Seal Overtravel Trim
Suffix “V22”
Linear Trim
Suffix “V15”
Trim Types
Pipe
AB
C
DE
Shipping
Weight
(lbs)
Dimensions (inches)
3/4
1
1 1/4
1 1/2
2
2 1/2
3
4
5.78
5.78
5.78
5.78
8.12
9.00
9.00
13.88
1.95
1.95
2.01
2.01
2.66
2.96
2.96
5.00
2.64
2.64
2.94
2.94
3.05
3.87
3.87
7.40
5.19
5.19
5.19
5.19
8.01
8.01
8.01
9.00
1.16
1.16
0.70
0.70
0.96
0.70
0.70
0.00
4.0
4.0
4.2
4.2
9.5
13
12
100
Linear with
Valve Seal Overtravel Trim
Suffix “V25”
3/4” - 3” NPT
4” FLANGE
