Guspro BB-8416884 - Specifications; Dimensions: inches

Specifications
Dimensions: inches
2/2
SERIES
K3A4
Notes: ➀ 1” W.C. Drop @ 2” W.C. Inlet Pressure, 1, 000 Btu/Cu.Ft. or more, 0.64 Specific Gravity Gas
➁ Standard lead length 18”
Pipe
Size
(ins.)
Orifice
Size
(ins.)
CV
Flow
Factor
Gas
Capacity ➀
Operating
Pressure
Differential
(psi)
Catalog Number ➁
Constr.
Ref. No.
Watt Rating/
Class of Coil
Insulation ➁
Btu/hr Min. Max.
24 V
60 Hz.
110-120 V
50-60 Hz.
220-240 V
50-60 Hz.
NORMALLY CLOSED (Closed when de-energized)
3/8 0.456 4 215,000 0 0.5 K3A431T K3A432T K3A434T 1 10/F
1/2 0.687 6 350,000 0 0.5 K3A441T K3A442T K3A444T 2 10/F
3/4 0.812 9 520,000 0 0.5 K3A451T K3A452T K3A454T 3 10/F
1 1.000 14 755,000 0 0.5 K3A461T K3A462T K3A464T 4 10/F
V7283
