Names of Parts Section 1-1
3. OUT1 (Control Output 1)
Lit while the control output function assigned to control output 1 is ON.
For a linear output, however, OFF only for a 0% output.
With position-proportional models, OUT1 is lit while the "open" output is
ON.
OUT2 (Control Output 2)
Lit while the control output function assigned to control output 2 is ON.
For a linear output, however, OFF only for a 0% output.
With position-proportional models, OUT2 is lit while the "close" output is
ON.
4. RST
Lit while the program is being reset
The RST indicator lights when an event or key operation changes the run/
reset status to reset during control operation.
5. CMW (Communications Writing)
Lit while communications writing is enabled and is not lit when it is dis-
abled.
6. MANU (Manual Mode)
Lit while the auto/manual mode is set to manual mode.
7. (Key)
Lit while settings change protect is ON (i.e., when the U and D Keys are
disabled by protected status.)
8. RSP
Lit while the SP Mode parameter is set to Remote SP Mode. (This indicator
is provided only on the E5AN-HT and E5EN-HT.)
9. FSP
Lit while the SP Mode parameter is set to Fixed SP Mode.
10. HOLD
Lit while the program is being held. (This indicator is provided only on the
E5AN-HT and E5EN-HT.)
11. WAIT
Lit while the program is in wait status.
Temperature Unit The temperature unit is displayed when parameters are set to display a tem-
perature. The display is determined by the currently set value of the Tempera-
ture Unit parameter. c indicates °C and f indicates °F.
Program Status Indicators The program status indicators show the direction of change of the present SP
in the present segment. The indicators light as follows: Rising segment: top
indicator, constant-temperature segment: middle indicator, and falling seg-
ment: bottom indicator. These indicators will turn OFF if any of the following
conditions are met.
• Reset status, standby status, not in Program SP Mode (i.e., in Remote or
Fixed SP Mode), or operation completed status.
Ir Indicates whether infrared communications is enabled. Lights when communi-
cations is enabled. Not lit when infrared communications is disabled.
• Infrared Communications Light Receiver
Used when infrared cable is used.
