GDS-1000A-U Series User Manual
16
Utility key
Utility
Configures the Hardcopy function
(page 112), shows the system
status (page 104), selects the menu
language (page 104), runs the self
calibration (page 128) and
configures the probe
compensation signal (page 129).
Help key
Help
Shows the Help contents on the
display (page 45).
Autoset key
Autoset
Automatically configures the
horizontal, vertical, and trigger
settings according to the input
signal (page 47).
Measure key
Measure
Configures and runs automatic
measurements (page 54).
Save/Recall key
Save/Recall
Saves and recalls images,
waveforms, or panel settings
(page 106).
Hardcopy key
Hardcopy
Stores images, waveforms, or
panel settings to USB (page 112).
Run/Stop key
Run/Stop
Runs or stops triggering (page 49).
Trigger level knob
LEVEL
TRIGGER
Sets the trigger level (page 95).
Trigger menu key
MENU
Configures the trigger settings
(page 95).
Single trigger key
SINGLE
Selects the single triggering mode
(page 102).
Trigger force key
FORCE
Acquires the input signal once
regardless of the trigger condition
at the time (page 102).
Horizontal menu
key
MENU
Configures the horizontal view
(page 84).
