3 or 4 Digit SMD Resistor Standards
For 3 or 4 digit SMD codes, the first 2 or 3 digits represent the base
value and the last digit represents the multiplier. The letter R is
used as a decimal point.
Example1: The code 220 equals 22Ω.
Example2: The code 12R0 equals 12.0Ω.
EIA-96 Code
The EIA-96 standard is a 3 letter code. The first 2 digits codify a
base value and the last digit is a letter that codifies a multiplier.
EIA-96 code is used for tolerances of 1%.
First Two Digits
Code
Value
Code
Value
Code
Value
Code
Value
Code
Value
Code
Value
01
100
17
147
33
215
49
316
65
464
81
681
02
102
18
150
34
221
50
324
66
475
82
698
03
105
19
154
35
226
51
332
67
487
83
715
04
107
20
158
36
232
52
340
68
499
84
732
05
110
21
162
37
237
53
348
69
511
85
750
06
113
22
165
38
243
54
357
70
523
86
768
07
115
23
169
39
249
55
365
71
536
87
787
08
118
24
174
40
255
56
374
72
549
88
806
09
121
25
178
41
261
57
383
73
562
89
825
10
124
26
182
42
267
58
392
74
576
90
845
11
127
27
187
43
274
59
402
75
590
91
866
12
130
28
191
44
280
60
412
76
604
92
887
13
133
29
196
45
287
61
422
77
619
93
909
14
137
30
200
46
294
62
432
78
634
94
931
15
140
31
205
47
301
63
442
79
649
95
953
16
143
32
210
48
309
64
453
80
665
96
976
