GW Instek GDS-2072A - Recall

GDS-2000A Series User Manual
202
Recall
File Type/Source/Destination
Item
Source
Destination
Default Panel
Setup
 Factory installed
setting
 Current front panel
Reference
Waveform
 Internal memory:
Ref1~4
 Current front panel
Panel Setup
(DSxxxx.set)
 Internal memory: S1 ~
S20
 File system: Disk, USB
 Current front panel
Waveform Data
(DSxxxx.lsf,
DSxxxx.csv**)
(CH1~CH4.lsf,
Ref1~Ref4.lsf,
Math.lsf)*
 Internal memory: Wave
1 ~ Wave20
 File system: Disk, USB
 Reference waveform
1 ~ 4
*Recalled from ALLXXX directories. Note that Allxxxx.csv cannot be
recalled to the oscilloscope.
**Detail CSV, LM Detail CSV and LM Fast CSV files cannot be recalled to
the oscilloscope.
Recall Default Panel Setting
Panel Operation
1. Press the Default key.
Default
2. The screen will update with the default panel
settings.
