REMOTE CONTROL CONFIG
229
Configure GPIB
To use GPIB, the optional module, DS2-GPIB, must be
installed. Please see page 30 for installation details.
1. Connect a GPIB cable from a PC to the installed
GPIB module.
2. Press the Utility key.
3. Press I/O from the bottom menu.
4. Use the Variable knob to set the
GPIB Address from the side menu.
This option will only be available
when the GPIB module is installed.
Maximum 15 devices altogether, 20m cable
length, 2m between each device
Unique address assigned to each device
At least 2/3 of the devices turned On
No loop or parallel connection
