BASIC OPERATION
45
Operation
1. Press F4 or F5 button for operating the corresponding
Series to enter the tracking series function. Yellow SER
will be shown on the status area.
2. Press CH1 button to proceed to CH1/CH2 voltage
setting and CH1 limit current setting.
3. Press CH2 button to proceed to CH2 limit current
setting.
4. For setting operation of parameter, refer to page 37.
Output
The button ON/OFF of CH1/CH2 is individually
available, while All ON/OFF button is available
for all channels.
CAUTION: under Tracking series mode, CH1 is master, whilst
CH2 is slave. Thus, output voltage setting is Not available for
CH2.
CH1/CH2 Tracking Parallel Mode
Load
+ -
