Enternal I/O Control
Description
The GPP series models
provides user with a
programmable external
trigger port, which is used
to dock certain functions
control.
Function
It can turn each Data Line
(D0,D1,D2,D3,D4) into input signal
respectively to have command of the
following four functions:
1. Control of channel On/Off
2. Control of Tracking mode
3. Toggle between PWR/Load modes
4. Toggle between CC/CV/CR modes
under Load
The conditions listed below for output
signal setting:
1. Channel output On/Off
2. Beyond the setting of
Voltage/Current/Power
