GW Instek GPP-3323 User Manual

BASIC OPERATION
79
2. Press F3 (Save) button to save the
temporary data into the
corresponding file.
3. Press F4 (Recall) button to save the
record data of file into the
temporary storage for further saving
into flash drive later.
Flash
drive
operation
descriptio
n
Note:
Type/*.CSV/ *.REC/New
File/Select buttons appear when
flash drive is selected.
 Type is used to select *.CSV and
*.REC file types.
 New File is used to create new file.
 Select is used to open the required
file folder.
Operation
ON/OFF
Press F5 (REC.On) button to enter
live record function. REC appears
on the status bar (the color of
channel remains the original when
single channel is enabled, whilst it
turns to white when multiple
channels are activated).

GW Instek GPP-3323 Specifications

General

Brand	GW Instek
Model	GPP-3323
Category	Power Supply
Language	English
