BASIC OPERA
TION
47
Note
The voltage (
≥
1V
) or
--
.
---
(
<
1V) pertaining to port
appears when Output
is Off.
Parameter
Description
Load
Under PWR. mode, press F
6 (Load
Mode) to enter the
Load mode. LCD
will display the
status
.
V
set
Set rating range of vo
ltage value
under Load mode of
active channel:
CH1
：
1
.5
0V
-33.00V
CH2
：
1
.5
0V
-33.00V
Iset
Set rating range of curre
nt va
lue
under Load mode of
active channel
CH1
：
0.
000A-3.200A
CH2
：
0.
000A-3.200A
Rset
Set rating range of resis
tance
value
under Load mode of
active channel
CH1
：
1
Ω
-1000
Ω
CH2
：
1
Ω
-1000
Ω
