GW Instek GPP-3323 User Manual

GPP Series User Manual
54
Parameter
Description
No.
Voltage
Current
Time
Group number. Maximum 2047
Voltage setting of each group.
Range: 0-33V
Current setting of each group.
Range: 0-3.2A
Execution duration of each group.
Range: 1S – 300S
Parameter
Setting
No.
Under the Sequence function, press
F2 (Edit) button followed by
selecting F1 (No.). The setting on
LCD is activated and appears in red
font color
. Use number
pad to set the parameters directly
and then press the F1 (Done) button
to confirm; or use arrow keys along
with scroll wheel to complete the
setting.
The F4 (Page Up)key and F5
(Page Down) key can jump directly
to the previous or next page,each 8
groups is a Page.
Voltage
Under the Sequence function, press
F2 (Edit) button followed by
selecting F3 (Voltage). The setting on
LCD is activated and appears in red
font color
. Use
number pad to set the parameters
directly and then press the F1 (V) or
F2 (mV) button to confirm; or use
arrow keys along with scroll wheel
to complete the setting.
