BASIC OPERATION
65
Groups
Under the Delay function, press the
F1 (Set) button followed by selecting
the F3 (Groups), the setting on LDC
will be activated and appears in red
font . Use number pad
for direct setting followed by
pressing F1 (Done) key to confirm; or
use arrow keys along with scroll
wheel to complete setting.
End State
Under the Delay function, press the
F1 (Set) button followed by selecting
the F3 (Groups), and 3 statuses
Last/Output on/ Output off will
appear in turn on LCD
. The one
displaying is what’s called the
current status.
Stop
Condition
Under the Delay function, a condition of
stopping operation can be set. When the
instrument monitors the condition, the
execution of delay function can be
terminated. press the F3 (Stop) button
and halt the operation by setting voltage
F2 (Voltage), current F3 (Current) and
power F4 (Power), or Stop infinitely by
F1 (None). The output state of the
instrument after stopping is determined
by the setting of "End State".
Operation
ON/OFF
Press the F5 (Delay On) button.
Output is open when output lights
up; whilst output is off when output
lights out. DLY appears on the status
bar (yellow for CH1, blue for CH2,
and white for both CH1 & CH2 on).
At this time, the F5 button will
become "Delay OFF", which can
