GW Instek PSP-2010 - Set up; Power up; Single Power Supply Connection

GETTING STARTED
15
Set Up
Power up
Panel operation
1. Set the rear panel
Voltage selector to the
correct position
according to the AC
mains voltage.
115V
230V
2. Connect the power
cord to the socket.
3. Turn On the power
switch. The display
becomes active in 2~3
seconds.
Single Power Supply Connection
Panel operation
When connecting the power supply to a load,
please ensure the safety guidelines below are
adhered to.
PSP Load
+OUT
-OUT
+IN
-IN
