5
Installing the switch
WARNING!
Keep the tamper-proof seal on a mounting screw on the chassis cover intact, and if you want to open the
chassis, contact the local agent of H3C for permission. Otherwise, H3C shall not be liable for any
consequence caused thereby.
Figure 3 Hardware installation flow for the H3C S3100V2-52TP Switch
Installing the switch in a 19-inch rack
The S3100V2-52TP switch is available with one pair of mounting brackets, as shown in Figure 4.
