H3C S3100V2-52TP Installation Guide

36
Item Specification
Interface attributes
• 1000Mbps, full duplex
• MDI/MDI-X, auto-sensing
Max transmission
distance
100 m (328.1 ft)
Transmission medium Category-5 (or above) twisted pair cable
Standards IEEE 802.3u
1000Base-X SFP port
Every S3100V2-52TP switch has four 1000Base-X SFP ports, including two combo ports paired with two
1000Base-T Ethernet ports, on the front panel. Table 10 list
s the 1000Base-X SFP transceiver modules
available for the H3C S3100V2-52TP Switch.
Table 10 1000Base-X SFP transceiver modules available for the H3C S3100V2-52TP Switch
Transceiver module
Central
wavelength
Connector Fiber
Max
transmission
distance
50/125 m,
multimode
550 m
(1804.46 ft)
SFP-GE-SX-MM850-A 850 nm
62.5/125 m,
multimode
275 m
(902.23 ft)
SFP-GE-LX-SM1310-A
10 km (6.21
miles)
SFP-GE-LH40-SM1310
1310 nm
40 km (24.86
miles)
SFP-GE-LH40-SM1550
40 km (24.86
miles)
SFP-GE-LH70-SM1550
1550 nm
9/125 m, single
mode
70 km (43.50
miles)
SFP-GE-LX-S
M1310-BI
DI
TX: 1310 nm
RX: 1490 nm
SFP-GE-LX-S
M1490-BI
DI
You must
use these
two
transceiver
models in
pairs.
TX: 1490 nm
RX: 1310 nm
LC
9/125 m, single
mode
10 km (6.21
miles)
SFP-STACK-Kit N/A N/A UTP/STP
1.5 m (4.92
ft.)
SFP-GE-T N/A RJ-45 UTP/STP
100 m
(328.08 ft.)
