1
Product overview
S3100V2-52TP panel views
Figure 1 S3100V2-52TP front panel view
1 2 3
4
5
6
7
8
9
10
11
12
13
(1) 10/100Base-TX auto-sensing Ethernet port (2) 10/100Base-TX Ethernet port LED
(3) 1000Base-X SFP combo port (4) 1000Base-X SFP combo port LED
(5) 1000Base-X SFP port (6) 1000Base-X SFP port LED
(7) Seven-segment LED (8) System status LED (PWR)
(9) Port mode LED (Mode) (10) Port LED mode switching button
(11) Console port (12) 1000Base-T Ethernet port LED
(13) 1000Base-T Ethernet port
Figure 2 S3100V2-52TP rear panel view
(1) AC-input power receptacle (2) Grounding screw
