H3C S6850 Series User Manual

1-10
Item S9850-4C S9850-32H
• With four LSWM18CQMSEC
modules: 1512 BTU/hr
• With four LSWM116Q modules:
1061 BTU/hr
• With four LSWM18QC modules:
856 BTU/hr
• With four LSWM124XG2Q
modules: 1239 BTU/hr
• With four LSWM124XGT2Q
modules: 1662 BTU/hr
• With four LSWM124XG2QFC
modules: 1239 BTU/hr
• With four LSWM124XG2QL
modules: 938 BTU/hr
• With four LSWM124TG2H modules:
1211 BTU/hr
• With four LSWM116FC modules:
1061 BTU/hr
• Single DC input: 672 BTU/hr
• Dual DC inputs: 710 BTU/hr
Maximum thermal
consumption
• With four LSWM18CQ modules:
2279 BTU/hr
• With four LSWM18CQMSEC
modules: 2552 BTU/hr
• With four LSWM116Q modules:
2102 BTU/hr
• With four LSWM18QC modules:
1692 BTU/hr
• With four LSWM124XG2Q
modules: 2102 BTU/hr
• With four LSWM124XGT2Q
modules: 2962 BTU/hr
• With four LSWM124XG2QFC
modules: 2102 BTU/hr
• With four LSWM124XG2QL
modules: 1774 BTU/hr
• With four LSWM124TG2H modules:
2348 BTU/hr
• With four LSWM116FC modules:
2102 BTU/hr
• Single AC input: 1283 BTU/hr
• Dual AC inputs: 1314 BTU/hr
• Single DC input: 1273 BTU/hr
• Dual DC inputs: 1286 BTU/hr
Heat dissipation
Heat dissipation
method
Air cooling
Ventilation aisles Front-to-rear or rear-to-front (based on the installed fan trays)
Reliability and availability
Power module
redundancy
2+1 or 2+2 redundancy 1+1 redundancy
Fan redundancy
Use two fan trays and provide 1+1
redundancy when the ambient
temperature is below 35°C (95°F)
4+1 redundancy
Hot swapping
Power modules and fan trays support hot swapping
Expander modules support hot swapping, but do not hot swap an expander module
when the device is starting up
Mean Time
45.8 27.2
