H3C S6850 Series User Manual

3-34
Technical specifications
Table3-16 Technical specifications
Item Specifications
Dimensions (H × W × D)
40.1 × 214 × 274 mm (1.58 × 8.43 × 10.79 in), including the connector but
excluding the ejector lever
Weight 2 kg (4.41 lb)
Power consumption (static) 15 W
Power consumption (typical) 37 W
Power consumption (fully
loaded)
60 W
LSWM18QC
The LSWM18QC interface module provides eight QSFP+ ports.
Figure3-13 LSWM18QC front panel
(1) QSFP+ port LED
(2) QSFP+ port
Ports and LEDs
For information about the ports and modules and cables available for the ports, see "QSFP+ port."
For information about the LEDs, see "QSFP+ port LED."
Technical specifications
Table3-17 Technical specifications
Item Specifications
Dimensions (H × W × D)
40.1 × 214 × 274 mm (1.58 × 8.43 × 10.79 in), including the connector but
excluding the ejector lever
Weight 2 kg (4.41 lb)
Power consumption (static) 15 W
Power consumption (typical) 22 W
Power consumption (fully
loaded)
30 W
LSWM124XG2Q
The LSWM124XG2Q interface module provides 24 SFP+ ports and 2 QSFP+ ports. All SFP+ ports
support MACsec.
1
2
