3-38
Ports and LEDs
For information about the ports and modules and cables available for the ports, see "SFP28 port"
and "QSFP28 port."
For information about the LEDs, see "SFP28 port LED" and "QSFP28 port LED."
Technical specifications
Table3-21 Technical specifications
Item Specifications
Dimensions (H × W × D)
40.1 × 214 × 274 mm (1.58 × 8.43 × 10.79 in), including the connector but
excluding the ejector lever
Weight 2 kg (4.41 lb)
Power consumption (static) 19 W
Power consumption (typical) 48 W
Power consumption (fully
loaded)
78 W
LSWM116FC
The LSWM116FC interface module provides 16 SFP28 ports. The SFP28 ports can operate as
Ethernet interfaces or FC interfaces. When they operate as FC interfaces, they support fiber
transceiver modules operating at different speeds and provide the FC service.
Figure3-19 LSWM116FC front panel
Ports and LEDs
For information about the ports and modules and cables available for the ports, see "SFP28 port"
and "FC interfaces."
For information about the LEDs, see "SFP28 port LED."
Technical specifications
Item Specifications
Dimensions (H × W × D)
40.1 × 214 × 274 mm (1.58 × 8.43 × 10.79 in), including the connector but
excluding the ejector lever
Weight 2 kg (4.41 lb)
Power consumption (static) 15 W
Power consumption (typical) 37 W
Power consumption (fully
loaded)
60 W
