2-16
Figure2-9 S6850-2C left panel
(1) Power module handle
(2) Chassis ear position at the power module side
(3) Primary grounding point
(4) Auxiliary grounding point
(5) Chassis ear position at the port side
(6) Fan tray handle
S9850-4C
Figure2-10 S9850-4C front panel
(1) Expansion module 1
(2) Expansion module 2
(3) Expansion module 4
(4) Expansion module 3
1 3
4
6
2
2 5
1
4
2
3
