H3C S6850 Series User Manual

3-26
Item Specifications
Rated output power 650 W
Melting current of power
module fuse
10 A/ 250 V
650 W DC power module (LSVM1DC650)
Figure3-4 LSVM1DC650 power module
(1) Latch
(2) Power module LED
(3) DC power receptacle
(4) Handle
For information about the LED, see "Power module LEDs."
Features
LSVM1DC650 is a power module with DC input and DC output. It can provide up to 650 W of output.
Table3-6 describes the features provided by the LSVM1DC650 power module.
Table3-6 Features provided by the LSVM1DC650 power module
Feature Description
Protection function
Protection for input overcurrent, input undervoltage, output overvoltage, output
short-circuit, and overtemperature.
Support for redundancy
The power modules can work in 1+1 redundant mode, and support load
sharing.
Support for hot swapping
You can install or remove a power module when the switch is operating
correctly.
Technical specifications
Table3-7 Technical specifications
Item Specifications
Dimensions (H × W × D) 40.2 × 50.5 × 326 mm (1.58 × 1.99 × 12.83 in), including the handle
Weight 1.07 kg (2.36 lb)
Rated input voltage range –40 VDC to –60 VDC
Max input voltage range –40 VDC to –72 VDC
1
2
3
4
