H3C S6850 Series User Manual

1-4
Item
LS-6850-56HF/LS-6850-
56HF-H1/S6850-56HF-S
AN
LS-6850-56HF-H3 S6850-2C
(H × W × D)
440 × 460 mm (1.72 × 17.32
× 18.11 in)
With package: 150 × 718 ×
556 mm (5.91 × 28.27 ×
21.89 in)
400 mm (1.73 × 17.32 ×
15.75 in)
With package: 150 × 658 ×
556 mm (5.91 × 25.91 ×
21.89 in)
440 × 660 mm (1.74 × 17.32
× 25.98 in)
With package: 150 × 812 ×
570 mm (5.91 × 31.97 ×
22.44 in)
Weight (with
all power
modules,
fans, and
expander
modules
installed)
≤ 15 kg (33.07 lb) ≤ 10 kg (22.05 lb) ≤ 16 kg (35.27 lb)
Technical specifications
Processor
LS-6850-56HF: 4 cores, 2.4
GHz
LS-6850-56HF-H1: 4 cores,
2.2 GHz
S6850-56HF-SAN: 8 cores,
2.2 GHz
4 cores, 2.2 GHz 4 cores, 2.4 GHz
DRAM
Memory
LS-6850-56HF: 8 GB
LS-6850-56HF-H1: 4 GB
S6850-56HF-SAN: 8 GB
4 GB 8 GB
NOR Flash
32 MB *2 (primary and
backup)
32 MB *2 (primary and
backup)
32 MB *2 (primary and
backup)
NAND Flash EMMC 4G EMMC 4G EMMC 4G
Interface types and quantity
Console ports
• 1 × Mini USB console
port
• 1 × serial console port
1 × serial console port
• 1 × Mini USB console
port
• 1 × serial console port
Management
Ethernet
ports
• 1 × 10M/100M/1000M
BASE-T copper port
• 1 × SFP port
1 × copper management
Ethernet port
• 1 × 10M/100M/1000M
BASE-T copper port
• 1 × SFP port
USB ports 1 1 1
SFP ports 2 N/A N/A
SFP28 ports 48 48 N/A
QSFP28
ports
8 8 2
IRF physical
ports
The following ports on the device panel and expander modules support IRF connection:
• QSFP28 ports (except for ports on the LSWM18CQMSEC interface module)
• QSFP+ ports
These ports support only 100 GE and 40 GE IRF connections, and do not support
1G/10G/25G/50G IRF physical connections.
Fans, power modules, and expansion modules
Fan tray slots 5 4 5
Power
2 2 2
