1-8
Item
LS-6850-56HF/LS-6850-
56HF-H1/S6850-56HF-S
AN
LS-6850-56HF-H3 S6850-2C
Humidity 5% RH to 95% RH, noncondensing
Compliance
Product
compliance
• Safety standards
• EMC standards
• Environmental and eco-friendly standards
Table1-2 H3C S9850 switch series technical specifications
Item S9850-4C S9850-32H
Physical specifications
Dimensions (H × W
× D)
Without package: 88.1 × 440 × 660 mm
(3.47 × 17.32 × 25.98 in)
With package: 215 × 830 × 580 mm (8.46
× 32.68 × 22.83 in)
Without package: 43.6 × 440 × 460 mm
(1.72 × 17.32 × 18.11 in)
With package: 150 × 718 × 556 mm
(5.91 × 28.27 × 21.89 in)
Weight (with all
power modules,
fans, and expander
modules installed)
≤ 27 kg (59.52 lb) ≤ 15 kg (33.07 lb)
Technical specifications
Processor
LS-9850-4C: 4 cores, 2.4 GHz
LS-9850-4C-H1: 4 cores, 2.2 GHz
LS-9850-32H-A: 4 cores, 2.4 GHz
LS-9850-32H-H1: 4 cores, 2.2 GHz
DRAM Memory 8 GB 8 GB
NOR Flash 32 MB *2 (primary and backup) 32 MB *2 (primary and backup)
NAND Flash
LS-9850-4C: EMMC 4G
LS-9850-4C-H1: EMMC 8G
LS-9850-32H-A: EMMC 4G
LS-9850-32H-H1: EMMC 8G
Interface types and quantity
Console ports
• 1 × Mini USB console port
• 1 × serial console port
• 1 × Mini USB console port
• 1 × serial console port
Management
Ethernet ports
• 1 × 10M/100M/1000M BASE-T
copper port
• 1 × SFP port
• 1 × 10M/100M/1000M BASE-T
copper port
• 1 × SFP port
USB ports 1 1
SFP ports 2 2
QSFP28 ports N/A 32
IRF physical ports
The following ports on the device panel and expander modules support IRF
connection:
• QSFP28 ports (except for ports on the LSWM18CQMSEC interface module)
• QSFP+ ports
These ports support only 100 GE and 40 GE IRF connections, and do not support
1G/10G/25G/50G IRF physical connections
Fans, power modules, and expander modules
