H3C SecPath F5030 User Manual

41
Figure 33 NSQM1G4XS4 front view
(1) LED (2) 1000Base-X fiber Ethernet ports
(3) 10GBase-R fiber Ethernet ports (4) Captive screw
(5) Ejector lever
NSQM1GT8A
The NSQM1GT8A interface module provides eight 10/100/1000BASE-T copper ports.
Figure 34 NSQM1GT8A front view
(1) LED (2) 10/100/1000BASE-T copper Ethernet ports
(3) Captive screw (4) Ejector lever
NSQM1GP8A
The NSQM1GP8A interface module provides eight 1000BASE-X fiber Ethernet ports.
Figure 35 NSQM1GP8A front view
(1) LED (2) 1000BASE-X fiber Ethernet ports
(3) Captive screw (4) Ejector lever
NSQM1GT4PFCA
The NSQM1GT4PFCA interface module provides four 10/100/1000BASE-T copper Ethernet ports
that support the bypass function.
