Page 34
Section 3 Technical Specifications
TYPICAL TECHNICAL DATA
Enclosure: Fiberglass Reinforced Polyester
Dimensions (HxWxD): 1000mm x 500mm x 320mm
Weight: Typically 50 kg
Power Consumption: 100 W (VA)
Mains Connection: 115V AC, 60Hz or 230V AC, 50Hz (10%)
Other power options are available on request.
Mains Wire Specification: Number of Cores = 3, Current Rating minimum = 10 Amps, CSA (Cross
Sectional Area minimum) = 1.50mm
2
Signal Wire Specification: Number of Cores = 6 (+2 cores per additional signal), Current Rating
minimum = 1 Amp, CSA (Cross Sectional Area minimum) = 0.22mm
2
FEATURES IN DETAIL
Display: High Contrast 40 Character x 16 Line Backlit LCD with LED Backlight
Data Storage: Previous 9999 analysis data on screen in the microcontroller memory and
storage of data archive for the lifetime of the analyzer in the SD/MMC card
Previous 99 fault data on screen in the microcontroller memory and storage
of fault data archive for the lifetime of the analyzer in the SD/MMC card
SD/MMC Card: Flash memory card for data transfer and for software & configuration updates
Operation: Microcontroller with BioTector OS3 Software and Membrane Keyboard
Language Options: English, French, German
Other language options are available on request.
INPUT & OUTPUT SIGNALS
Standard Output: 4 programmable 4-20mA analog output signal channel fitted as standard
Maximum impedance: 500 ohms
Digital Output: 6 freely programmable system relays (volt free changeover contact with a
current rating of 1Amp at 30V DC)
One of the relays is preprogrammed as system fault relay as standard.
Data Transfer Port: SD/MMC Card
