Hach BioTector B3500ul - Analyzer Dimensions and Mounting

Page 51
5.2.1 Analyzer Dimensions and Mounting
The BioTector TOC analyzer enclosure is a Fiberglass Reinforced Polyester (FRP) cabinet. This enclosure
facilitates easy access to all components and thus eases the service and maintenance procedures. Figure 7
and table 4 below gives the dimensions of BioTector enclosure.
Figure 7 BioTector Dimensions
Table 4 BioTector Dimensions
Height
Width
Depth
BioTector TOC Analyzer
1000mm
500mm
320mm
