Table 2 BioTector major components
1
Power and Input/Output Board
2
NDIR CO
2
Analyzer
3
Ferrite
4
Acid Pump, P3
5
Base Pump, P4
6
Ozone Line Filter
7
Main Power Switch
8
Cooler
9
Ozone Generator
10
Sample Pump, P1
11
Sample Sensor
12
Reactor Valve, MV3
13
Manual Grab Sample/Calibration Valve, MV5 or Multi-stream Valve, MV6
14
Mixer Reactor
15
Ozone Destructor
16
Sample Valve, MV4
17
Liquid Leak Detector
18
Exhaust Valve, MV1
19
Fan
20
Oxygen (O
2
) Tank
21
Termination Board
22
Molecular Sieve Bed
23
Oxygen Pressure Regulator
24
Hepa Filter
25
Cooler Fan
26
Sample Pump Motor
27
Oxygen (O
2
) Controller Board
28
Mass Flow Controller (MFC)
29
Filter Board
30
Rotary Valve, OV2
31
Air Isolation Valve, OV1
32
Pressure Relief Valve
33
Reactor Motor, P2
34
Exhaust Filter
35
Mixer Reactor Liquid Leak Detector
