Hach POCKET COLORIMETER II Instruction Manual

2—15
User-Entered Calibration
Overview
The Pocket Colorimeter™ II will accept a user-prepared calibration curve. The
curve can extend from 0 to 2.5 absorbance. A user-prepared calibration curve
may be entered into any channel that does not contain a factory-programmed
curve. These channels are labeled “abs” on instruments having a single factory
calibration or are labeled “1” and “2” on the uncalibrated single wavelength
instruments. Any chemistry that can be run at the instrument wavelength may
be user-entered in these channels.
Using prepared standard solutions that cover the range of interest, the meter
generates a calibration curve by calculating the straight-line segments
between each standard entered. A calibration curve may be entered using the
keypad. Factory-entered calibration curves may also be recalculated or
adjusted using the same procedure.
To enter the user-entered calibration mode, press the
MENU key and hold it
down until the display shows “USER” (about 5 seconds), followed by “CAL”.
Press
ZERO/SCROLL to scroll through the options.
Note: If the meter does not display USER followed by CAL after pressing the
MENU key, the factory calibration cannot be modified on this channel.
5957088.book Page 15 Friday, March 22, 2013 3:54 PM

Hach POCKET COLORIMETER II Specifications

General

Measurement Method	Colorimetric
Display	LCD
Operating Temperature	0 to 50 °C
Storage Temperature	-40 to 60 °C
Waterproof Rating	IP67
Weight	0.23 kg
Light Source	LED
Range	Varies by parameter
Wavelength	Varies by parameter
Battery Life	Approximately 2000 tests
