Haier HB21FSSAA Service Manual

SERVICE MANUAL
Model: HB21FSSAA
,
HB21FG*
25
Issue 2010-12
Rev.
Ref1012S008V0
4-11. Power outage memory function
When refrigerator has a power outage, the instantaneous working status during the outage is
memorized. After the power is on, the refrigerator will still run according to the setting tags and
function states before the power outage.
Caution: The Lock function is not memorable. The refrigerator is at unlocked status after power
recovery.
4-12. Demo mode
Under locked status, press the function confirmation button OK (B) and freezer temperature control
button FRZ TEMP (C) at the same time for 3 seconds to active demo mode.
Demo mode can be used for demonstrating refrigerator in market or showroom. Under demo mode,
compressor, fan and heater are all not work, the lamp can work normally.
Same above operation under locked status can exit the demo mode.

Haier HB21FSSAA Specifications

General

Icemaker	No
Noise level	42 dB
Climate class	SN-T
Total net capacity	543 L
Total gross capacity	635 L
Child lock	-
Product color	Stainless steel
Built-in display	Yes
Appliance placement	Freestanding
Number of compressors	1
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	10 kg/24h
Freezer net capacity	149 L
Freezer gross capacity	- L
Freezer number of shelves/baskets	2
Storage time during power failure	12 h
Fridge net capacity	394 L
Fridge number of shelves/baskets	3
Connected load	- W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Annual energy consumption	432 kWh
Package depth	760 mm
Package width	980 mm
Package height	1860 mm
Package weight	161000 g

Weight and Dimensions

Depth	770 mm
Width	910 mm
Height	1780 mm
Weight	141000 g
