SERVICE MANUAL
Model: HB21FSSAA
,
HB21FG*
28
Issue 2010-12
Rev.
Ref1012S008V0
Chapter 6 Cooling System Principle
6-1.Cooling system flow scenograph
6-2.Cooling system flow chart
(1) Compressor
(2) Connector pipe
(3) Condenser
(4) Anti-dew tube
(5) Drier filter
(6) Capillary
(7) Evaporator
(8) Suction pipe
(9) Connector pipe
(10) Condenser cooling fan
(11) Freezing fan
(12) Defrost heater
(1) Compressor
(2) Condenser
(3) Drier filter
(4) Capillary
(5) Evaporator
(6) Freezing fan
