Haier HB21FSSAA Service Manual

SERVICE MANUAL
Model: HB21FSSAA
,
HB21FG*
35
Issue 2010-12
Rev.
Ref1012S008V0
fridge/freezer storage
compartment is dirty,
worn, cracked or
mismatched.
 The condenser is dirty.
Leakage gap of door gasket can cause
longer running time of the refrigerator in
order to maintain desired temperature.
 Clean the condenser.
Too high temperature
Too high temperature in
the fridge/freezer
storage compartment
 The door is opened too
frequently or for too
long periods of time
 Temperature is set too
high
 The door is not closed
tightly
 The condenser is dirty
 Warm air will enter the refrigerator
whenever the door is opened. Try to open
the door as infrequently as possible.
 Reset the temperature.
 Make sure the refrigerator is on a level
surface and there is no food or container
interfering with the door.
 Clean the condenser.
The temperature in the
freezer storage
compartment is too high
while the temperature in
the fridge storage
compartment is OK
 The temperature is set
too high
 Set the freezer temperature lower. It
takes 24 hours for the temperature of the
refrigerator to become stable.
The temperature in the
fridge storage
compartment is too high
while the temperature in
the freezer storage
compartment is OK
 The temperature is set
too high
 Set the fridge temperature lower. It takes
24 hours for the temperature of the
refrigerator to become stable.
Bad odors in the refri
g
erato
r
The inside of the
refrigerator is dirty
 The inside of the
refrigerator needs
cleaning
 Food with strong odor is
stored in the refri
g
erato
r
 Clean the internal of the refrigerato
r
 Wrap the food tightly.
If you hear...
Beeps  The fridge storage
compartment door is
open
 The temperature in the
freezer storage
compartment is too high
 Close the door or silence the alarm
manually
 The alarm is normal when it is first started
due to relatively higher temperature.
Abnormal sound  The refrigerator is not
located on a level
surface
 The refrigerator touches
some object around it
 Adjust the feet to level the refrigerator.
 Remove objects around it.
Slight sound similar to
that of flowing water
 It is the sound of the
refrigerating system
 Normal.
Heating of cabinet  The de-dew tube is
de-dewing
 It is a process to prevent dewing. It is a
normal phenomenon.

Haier HB21FSSAA Specifications

General

Icemaker	No
Noise level	42 dB
Climate class	SN-T
Total net capacity	543 L
Total gross capacity	635 L
Child lock	-
Product color	Stainless steel
Built-in display	Yes
Appliance placement	Freestanding
Number of compressors	1
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	10 kg/24h
Freezer net capacity	149 L
Freezer gross capacity	- L
Freezer number of shelves/baskets	2
Storage time during power failure	12 h
Fridge net capacity	394 L
Fridge number of shelves/baskets	3
Connected load	- W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Annual energy consumption	432 kWh
Package depth	760 mm
Package width	980 mm
Package height	1860 mm
Package weight	161000 g

Weight and Dimensions

Depth	770 mm
Width	910 mm
Height	1780 mm
Weight	141000 g
