Haier HB21FSSAA Service Manual

SERVICE MANUAL
Model: HB21FSSAA
,
HB21FG*
7
Issue 2010-12
Rev.
Ref1012S008V0
4
Aesthetics
Colors: W=white G=silver gray
B=Obsidian SS=stainless steel
Stainless
Steel
RED BLACK WHITE
Fascia panel / Handle (w / c) G/G G/G G/G G/G
F= flat / R= rounded / S= streamline R R R R
Inside colour W w w w
Compartments number 2n° 2n° 2n° 2n°
Bottle compartment 6n° 6n° 6n° 6n°
Hinged (r =right l =left) / reversible r / X r / X r / X r / X
Shelves:
Number Fridge / Freezer 3 / - 3 / - 3 / - 3 / -
Type (gr=grill / g=glass / p=plastic) g g g g
Color w-white / b=blue / t=transparent. t t t t
Adjustable (Y=yes / N=not) y y y y
Foldable Shelf yes yes yes yes
Bottle Rack yes yes yes yes
Drawers:
Plastic drawers (fully freezing comp.) 3n°. 3n°. 3n°. 3n°.
Colour of drawer (w=white/t=transp./g=green) t t t t
Crisper:
Chiller / Meat (salad crisper) transparent / white Chiller (t) Chiller (t) Chiller (t) Chiller (t)
Vegetable crisper(s) transparent / white t t t t
5
Equipment & accessories
Control panel
Interior / exterior Exterior Exterior Exterior Exterior
Thermometer interior / exterior Interior Interior Interior Interior
Display type LCD LCD LCD LCD
Control lamps green / yellow /white W W W W
Over temperature alarm LED / acoustic acoustic acoustic acoustic acoustic
Adjustable thermostat yes yes yes yes
Fast freeze switch /-function yes yes yes yes
Deodorizing yes yes yes yes
Interior light yes yes yes yes
LED light Full Full Full Full
Freeze pack(s) 2n° 2n° 2n° 2n°
ice maker Manual/ Automatic M M M M
Ice cube tray(s) 1n° 1n° 1n° 1n°
Butter holder yes yes yes yes
Egg trays 2 2 2 2
Adjustable feet front / rear 2n° 2n° 2n° 2n°
Length of cable/incl. plug 200cm 200cm 200cm 200cm
Condenser Back wall / Integrated I I I I

Haier HB21FSSAA Specifications

General

Icemaker	No
Noise level	42 dB
Climate class	SN-T
Total net capacity	543 L
Total gross capacity	635 L
Child lock	-
Product color	Stainless steel
Built-in display	Yes
Appliance placement	Freestanding
Number of compressors	1
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	10 kg/24h
Freezer net capacity	149 L
Freezer gross capacity	- L
Freezer number of shelves/baskets	2
Storage time during power failure	12 h
Fridge net capacity	394 L
Fridge number of shelves/baskets	3
Connected load	- W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Annual energy consumption	432 kWh
Package depth	760 mm
Package width	980 mm
Package height	1860 mm
Package weight	161000 g

Weight and Dimensions

Depth	770 mm
Width	910 mm
Height	1780 mm
Weight	141000 g
