When a tip ID has not been entered, or when
a tip is NOT inserted into the FM -2027, the fol-
lowing procedure obtains:
1. Turn the power switch ON.
2. The display will show I 0D\ (Tip ID number)
and the LED on the connector will flash. The
display will show the set temperature and
{EB-
3. Enter tip ID as follows:
Insert the tip ID end of the tip into the pro-
cess gate until the buzzer sounds ONCE.
Tip ID data are displayed for one second.
The display then shows IS~f I The LED
indicator will stop flashing, indicating that
the data are now stored. Once the tip is
inserted into the connector, heat control
begins.
4. When the set temperature is reached, the
buzzer sounds and the heater lamp at the
lower right of the temperature display starts
blinking.
When a tip ID has been entered, or when a tip
is inserted into the FM-2027, the following pro¬
cedure obtains:
1. Turn the switch ON.
2. The display will show the initial temperature
setting.
3. Heat control begins.
Tip ID displayed
Turn the switch
ON.
I
I
f
Set temperature displayed
icn
Ou
▼
Set temperature.
Heat control begins.
Enter tip ID.
Insert tip
EZS--
XX
NOTE:
The FM-202 is preset at 750®F. at the factory.
Check the temperature setting by pressing the o button.
The set temperature will be dispiayed for two seconds.
NOTE;
If the buzzer sounds three times when the tip is inserted
into the process gate, there has been a reading error.
Reinsert the tip.
^CAUnON:
Refrain from inserting foreign objects, the wrong end
of the tip, or Incompatible tips into the process gate.
Damage may result. __
• Factory settings
The FM-202 comes from the factory with the
following values preset:
Temoerature scale
cm
Fahrenheit
Auto power shutoff.
1 m
■ J V ■
disabled
Low temperature alarm setting
300'’F
Resetting the supervisor or
operator control setting
FTHl
Tip ID controlted
with inserting the
card.
Set temperature
TO
750^
