Hakko Electronics FR-803 - OPTIONAL PARTS; Vacuum Function Inoperative Nozzles

22
CAUTION
Do not use
No. A1124B
Single ø2.5 (0.09) and
No. A1142B
Bent Single 1.5 × 3 (0.06 × 0.12) nozzle with the
HAKKO FR-803. These nozzles do not have space to blow hot air, using them with the HAKKO FR-803 may result
in danger.
A1124B Single Ø2.5
(0.09)
Ø2.5 (I.D)
(0.09)
A1130 Single Ø4.4
(0.17)
A1133
SOP 7.5
× 15
(0.3
× 0.59)
A1131
SOP 4.4 × 10
(0.17 × 0.39)
A1132
SOP 5.6 × 13
(0.22
× 0.51)
Ø4.4 (I.D)
(0.17)
4.8 (0.19)
10 (0.39)
5.7 (0.22)
15 (0.59)
7.2 (0.28)
16 (0.63)
A1134
SOP 7.5
× 18 (0.3 × 0.7)
7.2 (0.28)
19 (0.75)
A1142B Bent Single
1.5 × 3 (0.06 × 0.12)
45°
1.5 (0.06) (I.D)
3 (0.12)
10
5
A1325 Dual Single Ø1.5 × 5-10
(0.06
× 0.2-0.39) Adjustable Pitch
ø1.5 (I.D
)
(0.06)
5 (0.2
)
10 (0.39)
A1183 SOJ 15 × 8
(0.59 × 0.31)
8
(0.31)
16 (0.63)
A1190 Dual Single
2.5 × 9.5 Pitch
(0.09 × 0.37)
A1191
SIP 25L
(0.98)
Ø2.5 (I.D)
(0.09)
26
(1.02)
2 (0.08)
A1192
SIP 50L (1.97)
52.5
(2.07)
2 (0.08)
� Vacuum function inoperative nozzles.
Unit: mm (inch)
The pitch
between the
two nozzles
is adjustable.
