4. PART NAMES
Station
Handpiece
Handpiece holder
Fuse
⑩
Power switch
Power receptacle
Slot for control
card
Handpiece holder
mounting screw
③
Airflow meter
①
File number display
②
Temperature/Timer display
Handpiece holder
mounting screw
④
Display steps
⑤
Airflow control knob
⑥
Mode selecting button
⑧
Vacuum indicator
③
Sensor (internal)
②
Vacuum pipe
Nozzle
(not included)
①
Pad
⑤
Vacuum pipe control knob
④
Hot air button
⑥
Vacuum button
⑦
AUTO, MANUAL indicator
⑨Settingbuttons
