4
Station
①
File number display
②
Temperature/timer display
③
Airflow meter
④
Display steps
⑤
Airflow control knob
⑥
Mode selection button
⑦
AUTO/MANUAL indicator
⑧
Vacuum indicator
⑨
Setting button
⑩
Power switch
Handpiece
①
Pad
②
Vacuum pipe
③
Sensor (internal)
④
Hot air button
⑤
Vacuum pipe control knob
⑥
Vacuum button
This section displays files 1 to 3 in Auto mode.
This section displays a temperature and timer setting time for each
step in AUTO mode.
CAUTION
The displayed and set temperature indicates the temperatures at the
sensor.
This meter indicates the airflow rate.
This section will be lit during every step in AUTO mode.
This knob controls the airflow. The airflow can be set in the range
of 5 to 20 l/min.
This button displays and selects the MANUAL and AUTO modes.
This indicator lights the selected mode.
This indicator lights when the vacuum pump is in operation.
Use this button for setting, determining and checking the file
number, temperature, timer, etc.
This switch turns the power ON and OFF.
The pad absorbs parts.
The pad is mounted on the tip of the vacuum pipe.
This sensor detects the temperature of the hot air.
●
MANUAL Mode
When the Start button is pressed, the unit begins blowing hot
air. When the Start button is pressed again, the unit begins
cooling and stops blowing hot air after reaching 100°C (200°F).
●
AUTO Mode
When the Start button is pressed again, the selected AUTO
program begins.
This knob controls the length of the vacuum pipe.
This button turns the vacuum pump ON and OFF.
