Using vacuum function inoperative nozzle
(see page 22.)
■
Attach the nozzle.
a. Retract the vacuum pipe to the shortest
length using the vacuum pipe control
knob. (See page 5, Figure 6)
b. Loosen the nozzle mounting screw.
Attach the nozzle. (See page 5, Figure 5)
c. Tighten the nozzle mounting screw.
CAUTION
The pad cannot be used with this type of nozzle.
C. Electrical Connection and Power ON
1. Connect the power cord to the power
receptacle on the back panel of the station.
(Figure 8)
2. Place the handpiece on the holder. (Figure 9)
3. Plug the power cord into a grounded wall
socket.
4. Turn the power switch ON.
(Figure 9) Top View
(Figure 8)
CAUTION
This product is ESD-protected. Be sure to use a
grounded wall socket.
CAUTION
When not in use, place the
handpiece on the holder.
To Next Page
