6. PARAMETER SETTING
The auto shutoff function works by default after the station is idle for 30 minutes and it automatically
enters a power save state.
● Auto shutoff function
With this function enabled, if you press the “S” button ( button) again during cooling, cooling is stopped.
This function is used when working temperature is low and you do not have to wait until automatic stop is
made. When the set temperature is 716℉ or more, the function is unavailable.
● Forced cooling bypass function
● Check of settings
CAUTION
Please do not use this function at high temperatures.
Pressing the button once allows you to check the settings of the set temperature and set
time in this order.
Example : When the set temperature is 650℉ and the timer setting is 150 seconds.
The HAKKO FR-810B has the following parameters:
Parameter No. Parameter name
℃ / ℉ selection
Auto sleep ON/OFF setting
Auto shutoff ON/OFF setting
Setting mode selection
The number of preset *
Password setting
Temperature setting mode **
Preset selection mode**
Offset setting mode**
Air flow mode**
Password***
Auto shutoff time setting
Timer mode
Forcedcoolingbypass
PresetconnectionON/OFFsetting
Value
C/F
0:OFF/1:ON
0:OFF/1:ON
0:Normal/1:Preset
(2pcs)〜 (5pcs)
0:
Open/1:Partial/2:Restricted
:○/ :×
:○/ :×
:○/ :×
:○/ :×
Select three letters
30〜60min(Set in units of minutes)
o:OpenTiming/c:ClosedTiming
0:OFF/1:ON
0:OFF/1:ON
Initial value
℉
1
1
0
0
-
30
o
0
0
* It is displayed only when "1:Preset mode" is selected in the setting mode.
** It is displayed only when "1:Partial" is selected in the password setting.
***It is displayed only when either "1:Partial" or "2:Restricted" is selected in the password setting.
