11. PARTS LIST
⑧
⑤
⑥
⑩
⑪
⑫
⑭
⑨
⑬
①，②
③
②
①
④
Item No.
⑦
⑧
⑨
⑩
⑪
⑫
⑬
⑭
⑮
⑯
Part No.
B5043
B5044
B5060
B5048
B5108
B5109
B5052
B5053
B5054
B2421
B2422
B2424
B2425
B2426
B2436
B3508
B3550
B3616
B2384
B5092
B2300
Part Name
Joint hose
Fuse/250V-10A
Fuse/250V-6.3A
Handpiece holder
P.W.B. / 100-127V
P.W.B. / 220-240V
Fan
Power unit
Power cord, 3 wired cord & American plug
Power cord, 3 wired cord but no plug
Power cord, 3 wired cord & BS plug
Power cord, 3 wired cord & European plug
Power cord, 3 wired cord & BS plug
Power cord, 3 wired cord & Australian plug
Power cord, 3 wired cord & Chinese plug
Power cord, 3 wired cord & American plug (B)
Power cord, 3 wired cord & SI plug
Power cord, 3 wired cord & BR plug
Inlet
Pump
Heat resistant pad
Specifications
100-127V
220-240V
U.S.A.
India
220V KTL, 230V CE
230V CE, U.K.
China
Item No.
①,②
①
②
③
④
⑤
⑥
Part No.
A5005
A5006
A5007
A5022
A5023
A5024
B5049
B5045
B5107
A1520
A1439
A1438
B3023
Part Name
Heating element assembly
Heating element assembly
Heating element assembly
Heating element
Heating element
Heating element
Mica
Pipe
Handle with cord assembly
Pad ø3 mm (0.12 in.)
Pad ø5 mm (0.20 in.)
Pad ø7.6 mm (0.30 in.)
Vacuum pipe adjustment knob (L)
Specifications
100-110V
120,127V
220-240V
100-110V
120,127V
220-240V
with heater protection sleeve
with pipe
Set of 5
Set of 5
Set of 5
With screw
● HAKKOFR-810B
⑮
⑯
⑧
⑦
