1. Features 1-1
Overview
1. Features
The V7 series inherits and heightens the features of the V6 series as described below.
1. 32k-color Display
32,768-color display makes colorful expression possible.
Bitmap files are clearly displayed in brilliant colors.
2. CF Card Interface as Standard
The CF card can be used for saving multiple screen data, sampling data, recipe data, hard copy
images, and other various usages.
Large-sized video capture images, JPEG or WAV files can be saved.
3. Connector for 10BASE-T (for high-performance type only)
This connector enables Ethernet connection with a host computer.
High-speed communications are possible via Ethernet for uploading/downloading screen data and
reading/writing data from/to the server.
4. Video Display Upgraded (for high-performance type only/optional)
The video display function is upgraded drastically to allow: saving the current video screen, taking
snapshots of multiple exposures, superimposing a semi-transparent operation screen on a video
display, showing four video channels at the same time, and so on.
5. Web Server Function (for high-performance type only)
The V7i screens are converted into HTML files and displayed on the WWW browser using the
Ethernet.
6. Animation Function
The animation function enables representation of the field close to the real image.
7. Play of WAV File (for high-performance type only/optional)
WAV files can be played with ease simply by connecting the option unit to the speaker.
It is possible to use sound for notifying the field conditions, such as an occurrence of an error. The
monitoring operator can work from a distance.
