1. Specifications 2-5
Specifications
Function Performance Specifications
*1 The number of setting memory locations is limited to 1024 per screen.
*2 Layer: 4 per screen (base + 3 overlaps)
Item Specifications
Screens Max. 1024
Screen Memory Flash memory: Appox. 4,992 kbyte (varies depending on the font)
Switch 768 per screen
Switch Actions
Set, reset, momentary, alternate, to light
(Possible to press a function switch and a switch on the display at the same time)
Lamps
Reverse, blink, exchange of graphics
768 per screen
Graphs
Pie, bar, panel meter and closed area graph: No limitation within 256 kbyte per screen
*1
Statistics and trend graphs: Max. 256 per layer
*2
Data
Setting
Numerical Data Display
No limitation within 256 kbyte per screen
*1
Character Display
No limitation within 256 kbyte per screen
*1
Message Display
Resolution: 640×480, max. 80 characters (1-byte)
800 × 600, max. 100 characters (1-byte)
No limitation within 256 kbyte per screen
*1
Sampling
Sampling display of buffer data
(Constant sample, bit synchronize, bit sample, relay sample, alarm function)
Graphic Library Max. 2560
Multi-Overlaps Max. 1024
Data Blocks Max. 1024
Messages Max. 6144 lines
Patterns Max. 1024
Macro Blocks Max. 1024
Page Blocks Max. 1024
Direct Blocks Max. 1024
Screen Blocks Max. 1024
Data Sheets Max. 1024
Screen Library Max. 1024
Animation (Frames) Max. 1023
Temperature Control
Network/PLC2Way Table
Max. 32
Time Display Time display function: provided
Hard Copy Screen hard copy function: provided
Buzzer Buzzer: provided, 2 sounds (short beep, long beep)
Auto OFF Function Always ON, random setting
Self-diagnostic Function
Switch self-test function
Communication parameter setting check function
Communication check function
