1-2 2. Models and Peripheral Equipment
2. Models and Peripheral Equipment
MONITOUCH Models
The model name consists of the following information.
The following models are available.
<Analog>
V 7
Power supply specification
D: 24 VDC specification (in compliance with CE/UL/cUL)
None: 100-240 VAC specification
Touch switch specification
None: Analog
M: Matrix
Device specification
S: TFT color LCD (SVGA)
T: TFT color LCD (VGA)
C: TFT 128-color LCD (VGA). . . . . . .10-inch
STN color LCD (VGA). . . . . . . . . .8-inch
Functional specification
i: High-performance type
None: Standard type
Screen size
08: 8-inch
10: 10-inch
12: 12-inch
Series and Size Model Name Specifications Remarks
V708 series
8-inch
V708SD TFT color, 800 × 600 dots, standard, DC power supply
Compliant with
CE/UL/cUL
V708iSD TFT color, 800 × 600 dots, high-performance, DC power supply
Compliant with
CE/UL/cUL
V708CD STN color, 640 × 480 dots, standard, DC power supply
Compliant with
CE/UL/cUL
V710 series
10-inch
V710T TFT color, 640 × 480 dots, standard, AC power supply
V710TD TFT color, 640 × 480 dots, standard, DC power supply
Compliant with
CE/UL/cUL
V710iT TFT color, 640 × 480 dots, high-performance, AC power supply
V710iTD TFT color, 640 × 480 dots, high-performance, DC power supply
Compliant with
CE/UL/cUL
V710S TFT color, 800 × 600 dots, standard, AC power supply
V710SD TFT color, 800 × 600 dots, standard, DC power supply
Compliant with
CE/UL/cUL
V710iS TFT color, 800 × 600 dots, high-performance, AC power supply
V710iSD TFT color, 800 × 600 dots, high-performance, DC power supply
Compliant with
CE/UL/cUL
V710C TFT color, 640 × 480 dots, standard, AC power supply
V710CD TFT color, 640 × 480 dots, standard, DC power supply
Compliant with
CE/UL/cUL
