5-10 9. Ethernet
- Screen data can be transferred from the V-SFT editor on the server to the V7 series.
• Communications between the Ethernet-ready PLC and the V7 series
- The V7 series can communicate with the PLC on the Ethernet.
- The V7 series can communicate with multiple PLCs on the Ethernet.
• For more information, refer to the PLC Connection Manual.
