5-16 10. Other Networks
T-LINK
• To use T-LINK communications on the V7 series, the communication interface unit “CU-01” must
be mounted. When the V7 series is equipped with the communication interface unit CU-01, it
becomes a T-LINK-ready device.
• The V7 series that supports T-LINK communications can perform long-distance high-speed data
transmission with the Fuji Electric's PLC MICREX-F series.
• The V7 series updates the display when the read data (V7 series ← PLC) is changed. The V7
series reads data from the PLC memory addresses that are allocated to the items placed on the
screen, such as lamp parts or counter parts.
When switch data or counter setting data on the V7 series should be written, the V7 series issues
a write command to the PLC and writes the output data to the PLC memory.
These operations are automatically performed on the V7 unit and no special communication
program is required on the PLC side.
PLC
D1
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
D1 D0 D0
F1
F2
F3
F4
F5
F6
F1
F2
F3
F4
F5
F6
Read operation
Lamp
Numerical data
display
Graph
V7 series
Write request to the PLC
Read request to the PLC
Write operation
Numerical
data/character
entry switch
