65
Maintenance and Care
cle using the lifting gear.
5.4.4 Installing the trough battery
Set the key switch to position 0
(refer to „Key switch“ in Section
3.2.3) and remove the key.
1. Open the side doors to the left and
right (Fig. 23/3).
2. Take hold of the seat console
(Fig. 23/1) at the handle (Fig. 23/2)
and
pivot it forwards to open it.
If a cab safety roof is fitted,
open the seat console from the
righ
t-hand side of the vehicle
otherwise your hands could be
crushed between the seat con-
sole and cab safety roof.
Install the trough battery in the vehicle
fr
om the left-hand side of the vehicle us-
ing lifting gear or a fork-lift truck accord-
ing to the adjacent figure.
Fig. 23
2
1
3
2
4
5
6
7
