67
Maintenance and Care
5.5 Solution tank
1 Solution tank
2 Opening to recovery tank
(airing and venting)
3Lid seal
4 Tank cap
5 Ball cock
6 Solution filter
7 Draining hose
8 Screw cap
Fig. 24
1
3
4
5
6
7
2
8
